C214-2052 – 400 Series Centrifugal Exhausters

This 400 series turbine by AutoVac is a multistage exhauster with 20 hp power. It handles 5-6 total simultaneous users and is built in-house to strict standards for reliable performance and durability. View more C214-2052 product specs and features below.

Product Specifications

  • Total Simultaneous Users:
    5-6
  • Number of Phase(s):
    3
  • Hose Length:
    15ft
  • Hose Diameter:
    1 1/2 in
  • Power @ 3600 RPM:
    20 hp
  • Vacuum Frame Dimensions:
    24” wide x 33” high x 48” long
  • Weight:
    750lb
  • Noise at 10 feet:
    72 db
  • Performance:
    3600 rpm

Product Features

  • Turbine blower casing is housed between two 1/2” thick 356 alloy aluminum head castings for strength, durability and heat dissipation.
  • Impellers are 6061-T6 aircraft grade aluminum and dynamically balanced to ensure operation below 1.5 mils at 3,600 RPMs.
  • Directional-controlled inlet and outlet air openings accelerate airflow and improve performance.
  • Two-bolt outboard flange bearings are self-aligning.
  • Extremely durable cast iron TEFC drive motor is aligned at the factory for vibration-free operation.
  • Sure Fit split drive couplings from motor to turbine driveshaft are constructed of durable polyurethane.
  • Motors and couplings can be serviced without removing the turbine blower section.
  • Sturdy iron rail frame with three point leg design and isolator pads prevent turbine from rocking on uneven mounting surfaces.

Additional Images
